LIFE Project: Improved small- and medium-scale production of vehicular biomethane using lignocellulosic agro-food waste in rural areas

  • Type Project
  • Status In progress
  • Execution 2024 -2027
  • Assigned Budget 3.893.996,00 €
  • Scope Europeo
  • Autonomous community Aragón
  • Main source of financing LIFE
  • Project website Web del proyecto
Description

The LIFE CHANDELIER project aims to demonstrate the technical and economic feasibility of a new, cost-effective, traceable, and sustainable biomethane production method from combined agri-food waste in rural areas. This biomethane will subsequently be used as an advanced transport biofuel in accordance with EU standards for automotive fuels (EN 16723-2:2018). The project will be evaluated at a demonstration site at the Valderrobres industrial biogas plant in Matarraña-Aragón, Spain.

Contextual description

Advanced biofuels, such as biomethane, are considered technically, economically, and sustainably viable alternatives to fossil fuels in a wide range of sectors, within the context of significantly reducing greenhouse gas (GHG) emissions and meeting EU environmental commitments. Biomethane can replace compressed natural gas (BioCNG) or liquefied natural gas (BioLNG) and offers competitive performance, particularly in long-haul heavy-duty freight vehicles.

The revised Renewable Energy Directive (RED II CE), as part of the Fit for 55 package (part of the European Green Deal), established binding targets and standards to ensure the uptake of renewable energy, including biomethane, in the transport sector. The RED II EC stipulates that fuel suppliers must provide at least 14% of road transport fuel as renewable energy by 2030. Within this 14% transport target, advanced biofuels made from animal manure, straw, nutshells, forest industry waste and wood products (known as lignocellulosic material), or from industrial waste unsuitable for food or feed chains, must account for at least 0.2% by 2022, 1% by 2025, and 3.5% by 2030. These targets ensure that biofuels from waste streams deliver genuine carbon reductions, rather than those from specific energy crops.

There are two main ways to produce biogas from agri-food waste: anaerobic digestion and biomass gasification. Anaerobic digestion is generally highly energy-efficient, relies on advanced biotechnologies, is more environmentally friendly, and helps reduce the problems caused by the leaching of nitrate-rich manure into soil and water.

Objectives
  • Develop and implement a pre-industrial scale demonstration plant.
  • Demonstrate the feasibility of using lignocellulosic waste to improve year-round biogas production.
  • Demonstrate the efficiency of the proposed biogas upgrading system to process different flow rates of biogas streams with varying compositions.
  • Analyze and validate the quality of vehicular biomethane for BioCNG fuel in freight transport.
  • Demonstrate a reduction in GHG emissions and other environmental impacts through a life cycle sustainability assessment (LCSA) and techno-economic analysis (TEA) to determine the sustainability and viability of the proposed business model.
Results
  • To demonstrate the technical feasibility of simultaneous pretreatment of thermoextrusion and co-digestion based on lignocellulosics to improve biogas production at two different scales.
  • Demonstrate a membrane technology capable of processing between 7 and 20 m3/hour of biogas from an innovative feedstock blend with a 95% methane content.
  • Biogas upgraded to vehicle-grade biomethane in accordance with European standards (EN16723-2:2018) and IVECO (Industrial Vehicles Corporation) quality requirements.
  • Performance of BioCNG produced in the project evaluated by a GUCO IVECO heavy truck over 120,000 km in 1 year.
  • 1.5% GHG reduction in the final year of the Demonstrator 2 project; Demonstrator 2 was replicated at 10 plants within 5 years of project completion, resulting in a 60% GHG reduction.
  • An optimized management methodology for lignocellulosic agro-food waste in the biogas production process (including seasonal crops, pig slurry, and by-products from the production of other plant and animal foods).
Contact information
  • Coordinator/entity name: Mª Eugenia Hernández
  • Postal address: CARRETERA COGULLADA, 65. MERCAZARAGOZA-CENTRORIGEN, 50014, Zaragoza,

Coordinators
  • ARAGON INNOVALIMEN
Collaborators
  • FUNDACIO EURECAT
  • GENIA BIOENERGY SL,INGENIERIA Y DESARROLLOS RENOVABLESSOCIEDAD LIMITADA,GANADERIA UNIDA COMARCAL GUCO S COOP,INSTITUTO TECNOLOGICO DE ARAGON
